12.6.3 PERC H800
The R910 can support up to four PERC 800 adapter cards for access to external SAS direct-attach
storage. Features of the PERC H800 include:
 LSI 2108 (Liberator) ROC
 6Gb/s SAS
 x8 PCIe Gen2
 800 MT/s Core PPC
 DDRII, 800 MT/s, mini-DIMM
 512MB dual mini-SAS connectors
 Supports connection to Dell PowerVault™ MD1220 and PowerVault MD1200 6Gb enclosures only
12.6.4 Storage Card Support Matrix
Table 13. Storage Card Support Matrix
Storage
Card
Usage
PowerEdge
R910
Support
Slot
PCIe
Con
PCI
Bracket
I/O
Con
RAID
Battery
Backup
PERC
SAS/
SATA
PERC H700
Integrated
Internal
Backplane
Storage
Yes—Max 1
Storage
slot
x8
No
2 x4
mini-
SAS int
0, 1, 5,
6, 10,
50, 60,
PRL-11
Yes
PERC H800
Adapter
External
SAS/SATA
Storage
Yes—Max 4
(PowerVault
MD1200 and
PowerVault
MD1220)
PCIe slot
x8
Yes
x4 ext
x4 ext
0, 1, 5,
6, 10,
50, 60,
PRL-11
Yes
PERC 6/E
Adapter
External
Legacy
Storage
Backup to
H800—Max 2
(MD1000
PowerVault
MD1000 only
and MD1020
PowerVault
MD1120)
PCIe slot
x8
Yes
x4 ext
x4 ext
0, 1, 5,
10, 50
Yes
SAS
HBA
SAS/
SATA
PERC H200
Integrated
Internal
Backplane
Storage
Yes—Max 1
Storage
slot
x8
No
x4 mini-
SAS int
0, 1, 10
No
6Gbps SAS
HBA
External
SAS tape
and
RBODs
Yes—Max 2
PCIe slot
x8
Yes
x4 int
None
No
SAS 5/E
Adapter
External
SAS
(DAS,
Tape)
Backup to
6Gbps SAS
HBA—Max 2
PCIe slot
x8
Yes
x4 ext
x4 ext
None
No

Dell PowerEdge R910 Specifications

General

Processor	Up to four Intel Xeon 7500 series processors
Form Factor	4U Rack Server
Storage	Up to 16 x 2.5" SAS, SATA, or SSD drives
RAID Controller	PERC H700, PERC H800
Network	Embedded Broadcom 5709c Gigabit Ethernet
Power Supply	Redundant 1100W power supplies
Expansion Slots	10 PCIe slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Memory	Up to 1TB DDR3 (64 DIMM slots)
