Dell™ Printer Configuration Web Tool 103
Right Frame
The right frame is located on the right side of all the pages. The contents of the right frame correspond to the menu
that you select in the left frame. For details on the items displayed in the right frame, see "Details of the Menu
Items."
Buttons in the Right Frame
Changing the Settings of the Menu Items
Some menus allow you to change the printer settings through the Dell Printer Configuration Web Tool. When you
access these menus, the authentication window appears on the screen. Type a user name and password for the
printer administrator by following the prompts displayed in the dialog box.
The default user name is admin, and the default password is left blank (NULL). You can change only the password in
the Set Password page in the Security menu. The user name cannot be changed. See "Set Password" for more
information.
Details of the Menu Items
1Refresh Button Receives the current printer configuration and updates the latest information in the right frame.
2 Apply New Settings
Button
Submits new settings made on the Dell Printer Configuration Web Tool to the printer. The new
settings replace the old settings of the printer.
3Restore Settings Button Restores the old settings that existed before any changes were made. New settings will not be
submitted to the printer.
"Printer Status" "Printer Status" "Printer Status"
"Printer Events"
"Printer Information"
1 2 3

Dell S2810dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Manual
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Printing colors	Black
Maximum duty cycle	40000 pages per month
Recommended duty cycle	500 - 3000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PostScript 3, XML
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Envelopes sizes	C5, DL, Monarch
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Pre-Printed, Recycled paper, Thick paper
Paper tray media weight	60 - 80 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Security algorithms	802.1x RADIUS, EAP-MD5, EAP-PEAP, HTTPS
Mobile printing technologies	Apple AirPrint, Dell Mobile Print, Google Cloud Print
Supported network protocols (IPv4)	HTTP, TCP, UDP, ICMP/IGMP, BOOTP, DHCP, RARP, Auto IP, WINS, DNS, Bonjour(mDNS), Telnet
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory type	DDR3
Maximum internal memory	- MB
Sound power level (standby)	24.7 dB
Sound pressure level (printing)	53.4 dB
Display	LCD
Certification	CE, FCC
Display number of lines	4 lines
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	45 W
Power consumption (printing)	560 W
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	15 - 85 %
Package depth	545 mm
Package width	528 mm
Package height	414 mm
Package weight	14600 g

Weight and Dimensions

Depth	438 mm
Width	410 mm
Height	273 mm
