Dell Studio XPS 8100 User Manual


1. Follow the procedures in Before You Begin.

2. Align and push the power button module tabs into the slots in the top panel.

3. Connect the power button module cable to the system board connector FP1 (see System Board Components).

4. Replace the top cover (see Replacing the Top Cover).

5. Replace the optical drive (see Replacing the Optical Drive).

6. Replace the front bezel (see Replacing the Front Bezel).

7. Replace the computer cover (see Replacing the Computer Cover).

8. Connect your computer and devices to electrical outlets, and turn them on.
Back to Contents Page


Dell Studio XPS 8100 Specifications

General

Optical Drive	16x DVD+/-RW Drive
Audio	Integrated 7.1 Channel Audio
Networking	Integrated 10/100/1000 Ethernet
Processor	Intel Core i5 or i7
Chipset	Intel H57
Memory	Up to 16GB DDR3 SDRAM
Storage	Up to 2TB HDD
Graphics	NVIDIA GeForce GT 220 or ATI Radeon HD 5770
Ports	8 x USB 2.0, 1 x eSATA, 1 x HDMI
Operating System	Windows 7 Home Premium
