Dell Studio XPS 8100 User Manual

1. Follow the procedures in Before You Begin.

2. Align and insert the front bezel clamps into the front panel slots.

3. Rotate the front bezel towards the computer until the front bezel tabs snap into place.

4. Replace the computer cover (see Replacing the Computer Cover).
Back to Contents Page

1
front bezel
2
front panel slots (3)
3
front bezel tabs (4)
4
front panel
5
front bezel clamps (3)

Dell Studio XPS 8100 Specifications

General

Optical Drive	16x DVD+/-RW Drive
Audio	Integrated 7.1 Channel Audio
Networking	Integrated 10/100/1000 Ethernet
Processor	Intel Core i5 or i7
Chipset	Intel H57
Memory	Up to 16GB DDR3 SDRAM
Storage	Up to 2TB HDD
Graphics	NVIDIA GeForce GT 220 or ATI Radeon HD 5770
Ports	8 x USB 2.0, 1 x eSATA, 1 x HDMI
Operating System	Windows 7 Home Premium
