Dell U3011 Setting Up

2/14
support.dell.com/support/edocs/monitors/u3011/en/ug/operate.htm
(Default)
2
Shortcut key 2 -
Brightness/Contrast (Default)
Use this button to directly access the "Brightness/Contrast" menu.
3
Shortcut key 3 - Input Source
(Default)
Use Input Source Select button to select between different video signals that may be connected to your monitor.
DVI-D 1
DVI-D 2
DisplayPort
VGA
HDMI 1
HDMI 2
Component
4
Menu
Use the MENU button to launch the on-screen display (OSD) and select the OSD Menu. See Accessing the Menu System.
5
Exit
Exit the On-Screen Display menu.
6
Power
(with power light indicator)
Use the Power button to turn the monitor on and off.
The blue LED indicates the monitor is on and fully functional. An amber LED indicates DPMS power save mode.
Using the On-Screen Display (OSD) Menu
Accessing the Menu System
NOTE: If you change the settings and then either proceed to another menu or exit the OSD menu, the monitor automatically saves those changes. The changes are also saved if you
change the settings and then wait for the OSD menu to disappear.
1. Touch the button to launch the OSD menu and display the main menu.
Main Menu for analog (VGA) Input
NOTE: Auto Adjust is only available when you use the analog (VGA) connector.
2. Touch the or button to move between the setting options. As you move from one icon to another, the option name is highlighted. See the following table for a complete
list of all the options available for the monitor.
3. Touch the button once to activate the highlighted option.
4. Touch the or button to select the desired parameter.
5. Touch the button to enter the slide bar and then use the and buttons, according to the indicators on the menu, to make your changes.
6. Touch the button to return to the main menu or to exit the OSD menu.

Dell U3011 Specifications

General

Pixel pitch	0.2505 mm
Aspect ratio	16:10
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Contrast ratio (dynamic)	100000:1
Display brightness (typical)	370 cd/m²
HDCP	Yes
USB hub version	2.0
DVI-D ports quantity	2
DVI-I ports quantity	-
USB Type-A downstream ports quantity	4
Input current	2.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	250 W
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	110 W
Product color	Black
Market positioning	Business
Package weight (imperial)	33.76 lbs
Panel mounting interface	100 x 100 mm
Package weight	15300 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %

Weight and Dimensions

Depth (without stand)	211.3 mm
Width (without stand)	694.5 mm
Height (without stand)	481.3 mm
Weight (without stand)	9300 g
