Installing the Hard Drive
1. Insert the hard drive assembly into its slot on the computer.
2. Tighten the screws that secure the hard drive to the computer
3. Connect the hard drive cable to the connector on the system board.
4. Install the:
a. battery.
b. back cover.
5. Follow the procedures in After Working Inside Your computer
Removing the Memory Module
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a. back cover.
b. battery.
3. Perform the following steps to remove the memory module:
a. Lift the plastic enclosure covering the top of the memory compartment. [1]
b. Pry the retention clips away from the memory module until it pops up. [2] Remove the memory
module from its connector on the system board. [3]
10
