Removing and Installing Components
This section provides detailed information on how to remove or install the components from your
computer.
Removing the Back Cover
1. Follow the procedure in Before Working Inside Your Computer.
2. Perform the following steps to remove the back cover:
a. Remove the screws that secure the back cover to the computer [1].
b. Pry the edges of the back cover from all sides, to release the back cover [2,3,4,5].
c. Lift the back cover from the computer [6].
Installing the Back Cover
1. Align the back cover with the screw holes on the computer.
2. Tighten the screws to secure the base cover to the computer.
3. Follow the procedures in After Working Inside Your computer.
Removing the Battery
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the back cover.
3. To remove the battery:
a. Disconnect the battery cable from the connector on the system board. [1]
b. Remove the screws that secure the battery to the computer. [2]
8
