Dell Vostro 14-5459 P68G User Manual

Installing the Memory Module
1. Insert the memory module into the memory socket.
2. Press the memory module down until it clicks into place.
3. Close the plastic enclosure which covers the memory module.
4. Install:
a. back cover.
b. battery.
5. Follow the procedures in After Working Inside Your computer.
Removing the WLAN Card
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
a. back cover.
b. battery.
3. To remove WLAN card:
a. Lift up the plastic flap which covers the WLAN card.
b. Remove the screw that secures the WLAN card to the computer.
c. Disconnect the antenna cable from the WLAN card.
d. Remove the WLAN card from its slot on the system board.
11

Dell Vostro 14-5459 P68G Specifications

General

Processor	Intel Core i5-6200U
Display	1366x768 pixels
RAM	DDR3L
Storage	256GB SSD
Graphics	Intel HD Graphics 520
Operating System	Windows 10 Home
Battery	3-cell
Dimensions	340 x 240 mm
