Installing the System Board
1. Install the system board into the slot on the computer chassis.
2. Install the screws that secure the system board to the computer chassis.
3. Connect the display assembly cable to the system board.
4. Install the:
a. memory module.
b. fan.
c. speakers.
d. keyboard.
e. hard drive.
f. IO panel.
g. DC-in connector.
h. display assembly.
i. heat sink.
j. WLAN card.
k. battery.
l. back cover.
5. Follow the procedure in After Working Inside Your computer.
22
