64 Removing and Installing Parts
Inside View of Your Computer
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions located in the
Product Information Guide.
CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before
opening the cover.
1 drive release latch 2 CD/DVD drive 3 power supply and fan
4 hard drive 5 heat sink assembly 6 power button
7 front-panel door
3
4
5
6
7
1
2
