68 Removing and Installing Parts
Addressing Memory With 4-GB Configurations
Your computer supports a maximum of 4 GB of memory when you use two 2-GB DIMMs. Current
operating systems, such as Microsoft
®
Windows
®
XP, can use a maximum of 4 GB of address space;
however, the amount of memory available to the operating system is less than 4 GB. Certain components
within the computer require address space in the 4-GB range. Any address space reserved for these
components cannot be used by computer memory.
Installing Memory
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions located in the
Product Information Guide.
NOTICE: To prevent static damage to components inside your computer, discharge static electricity from your
body before you touch any of your computer’s electronic components. You can do so by touching an unpainted
metal surface on the computer chassis.
1
Follow the procedures in "Before You Begin" on page 61.
2
Remove the CD/DVD drive (see "Removing a CD/DVD Drive" on page 81).
3
Remove the optional Media Card Reader or optional floppy drive, (see "Removing a Media Card
Reader" on page 85 or "Removing a Floppy Drive" on page 89) if installed.
4
Press out the securing clip at each end of the memory module connector.
1 memory connector closest to processor 2 securing clips (2) 3 connector
2
3
1
