Removing and Installing Parts 83
Installing a CD/DVD Drive
1
Unpack the drive and prepare it for installation.
Check the documentation that accompanied the drive to verify that the drive is configured for your
computer.
2
Connect the power and data cables to the drive.
3
Connect the data cable to the system board connector on the system board.
1 data cable 2 power cable 3 system board connector
2
1
3
