Figure 5-14 : Insulation Setting
Install Settings
21. Jun 2010 13:50
Inverter ID
Insulation
RCMU
Country Germany MV
[ 001 ]
[ --- ]
Grid Settings
[ ]
Reconnection Time
[
]
60 S
Ramp-up Power
20
%/m
Insulation
21. Jun 2010 13:50
Mode
Resistance
ON
200
[
[
]
] kohm
EXIT
ENT
Figure 5-15 : Grid Setting Page
21. Jun 2010 13:50
Grid Settings – 5/5
Reconnection Time
[ ]60 s
21. Jun 2010 13:50
Grid Settings – 3/5
Fac High Off
Fac High On
Fac High Off T
Fac Low Off
Fac Low On
Fac Low Off T
52.00 Hz
51.95 Hz
2.0 s
48.00 Hz
48.05 Hz
2.0 s
[
[
[
[
[
[
]
]
]
]
]
]
21. Jun 2010 13:50
Grid Settings – 2/5
Vac High Off Slow
Vac High On Slow
Vac High Off Slow T
Vac Low Off Slow
Vac Low On Slow
Vac Low Off Slow T
310.0 V
305.0 V
2.0 s
216.0 V
221.0 V
2.0 s
[
[
[
[
[
[
]
]
]
]
]
]
21. Jun 2010 13:50
Grid Settings – 1/5
Vac High Off
Vac High On
Vac High Off T
Vac Low Off
Vac Low On
Vac Low Off T
364.0 V
359.0
V
0.0 s
135.0 V
140.0 V
0.1 s
[
[
[
[
[
[
]
]
]
]
]
]
21. Jun 2010 13:50
Grid Settings – 4/5
Fac High Off Slow
Fac High On Slow
Fac High Off Slow T
Fac Low Off Slow
Fac Low On Slow
Fac Low Off Slow T
52.00 Hz
51.95 Hz
2.0 s
48.00 Hz
48.05 Hz
2.0 s
[
[
[
[
[
[
]
]
]
]
]
]
Grid settings page includes the voltage and frequency protection points.
These protection points are linked to electricity regulations.
If there is no any special requirement, please do not change any grid settings.
5.3.7.3.2 Grid Settings
Inverter will measure the impedance between Array and PE before connect to grid.
If the impedance between Array and PE is lower than the value that set in Insulation
Settings, inverter will stop connecting to grid. There are 4 modes users can select in
Insulation settings: ON, Positive Ground, Negative Ground, or Disable. Installer can
also select different impedance according to the actual situation.
5.3.7.3.1 Insulation
55
Turn on PV Inverter
