DVP-ES3 Series Operation Manual
1-2
_1
1.1 Overview
This manual introduces the DVP-ES3 Series PLC functions, devices, module tables, troubleshooting, and so
forth.
1.1.1 Related Manuals
The related manuals for DVP-ES3 Series programmable logic controllers are listed below.
 DVP-ES3 Series Programming Manual
This introduces programming for the DVP-ES3 Series programmable logic controllers, basic instructions,
and applied instructions.
For DVP-ES2 Series PLC, refer to DVP-ES2-/EX2-SS2/SA2/SX2/SE & TP Operation Manual –
Programming.
 ISPSoft User Manual
This introduces the use of the ISPSoft software, programming language (Ladder, SFC, FBD, and ST),
POUs, and tasks.
DVP-ES3 Series PLC can only use ISPSoft for programming, NOT WPLSoft.
 DVP-ES3 Series Operation Manual
This introduces electrical specifications, dimensions, CPU functions, devices, module tables,
troubleshooting, and so forth.
1.1.2 Models Descriptions
Classification Model Name Description
DVP-ES3
Series CPU
module
DVP32ES311T
24 VDC powered CPU module
NPN output, 1x Ethernet port, 2x RS-485 ports, 1x USB
port, 1x Micro SD interface, supporting 32 I/Os
(16DI+16DO) and up to 256 I/Os. Program capacity: 64K
steps, removable terminal blocks
DVP32ES300T
100-220 VAC powered CPU module
NPN output, 1x Ethernet port, 2x RS-485 ports, 1x USB
port, 1x Micro SD interface, supporting 32 I/Os
(16DI+16DO) and up to 256 I/Os. Program capacity: 64K
steps, removable terminal blocks
DVP32ES300R
100-220 VAC powered CPU module
Relay output, 1x Ethernet port, 2x RS-485 ports, 1x USB
port, 1x Micro SD interface, supporting 32 I/Os
(16DI+16DO) and up to 256 I/Os. Program capacity: 64K
steps, removable terminal blocks
DVP48ES300T
100-220 VAC powered CPU module
NPN output, 1x Ethernet port, 2x RS-485 ports, 1x USB
