The components of M80/60U is shown as Figure 2-1.
2.2 Product Overview
Table 2-1: Packing list of M80/60U
Figure 2-1: Components of M80/60U
①
⑧⑦
③ ④
⑤ ⑥
②
3 pcsScrew
Ground bar mounting screws (121/122 Models)
(Stainless/M5/21mm)
M80U / M60U
Object Qty Description
1 Delta Solar Inverter 1 pc
1 pc
1 pc
Solar inverter
2 Wiring Gland 1 pc For communication port wiring
3 User Manual
Important instructions for solar inverter
Safety instructions should be followed
during installation and maintenance
4 Mounting Bracket
Wall mounting bracket
(Material: Aluminum/Thickness: 3mm)
Al Alloy Busbar 1 pc DC side PE/EGC Ground bar (121/122 Models)
⑨
For 121/122 modelsFor 122 models
9
MC4 connector 18 pairs String inputs for M80/60U
_122 models
5 pcsScrew
To secure inverter to mounting bracket
(Stainless/M6/12mm)
8
6
5 1 pairShielding plate Shelding plate for filter (use is optional)
7
