Delta VFD-EL-W Series User Manual

Chapter 4 Parameters｜VFD-EL-W
64
4-3 Description of Parameter Settings
00 User Parameters
 You can set this parameter during operation.
00.00
AC Motor Drive Identity Code
Default: #.#
Settings
Read only
00.01
AC Motor Drive Rated Current Display
Default: #.#
Settings
Read only
 Pr.00.00 displays the AC motor drive identity code. The identity code includes the drive’s
capacity, rated current, rated voltage and the maximum carrier frequency. Use the following
specification table to check if the AC motor drive is correct.
 Pr.00.01 indicates the drive’s rated output current. You can use it to check if the AC motor drive
is correct.
Table for capacity, identity code and rated current:
230V Models
Power (kW)
0.2
0.4
0.75
1.5
2.2
Power (HP)
0.25
0.5
1.0
2.0
3.0
Identity Code
0
2
4
6
8
Rated current
1.6
2.5
4.2
7.5
11.0
Carrier Frequency
12 kHz
460V Models
Power (kW)
0.4
0.75
1.5
2.2
4.0
5.5
Power (HP)
0.5
1.0
2.0
3.0
5.5
7.5
Identity Code
3
5
7
9
11
13
Rated current
1.5
2.5
4.2
5.5
9.0
13
Carrier Frequency
12 kHz
00.02
Parameter Reset
Default: 0
Settings
0: Parameter can be read/written
1: All parameters are read only
7: Keypad and frequency setting knob locked
8: Keypad lock
9: Reset all parameters to defaults (50 Hz, 230V/400V or 220V/380V
depends on Pr.00.12)
10: Reset all parameters to defaults (60 Hz, 220V/440V)
 9 or 10: Reset all parameters to defaults when the parameters settings are abnormal.
 9: Resets all parameters to defaults for 50 Hz; the base voltage depends on the setting for
Pr.00.12.
 1: All parameters are read-only and cannot be changed. Err displays when you enter any input.
