Delta VFD-EL-W Series User Manual

Chapter 4 Parameters｜VFD-EL-W
87
03 Output Function Parameters
 You can set this parameter during operation.
03.00
Multi-Function Output Relay
Default: 8
Settings
0–23
 Summary of Function Settings
ID*
Functions
Descriptions
0
No function
Output terminal with no function
1
Indication during RUN
This contact is closed when the drive is ready or RUN command
is ON.
2
Indication of Master
Frequency Reached
This contact is closed when output frequency of drive reaches to
the setting frequency.
3
Indication at zero speed
This contact is closed when the drive output frequency is smaller
than the start-up frequency.
4
Over-torque detection
This contact is closed when the drive detects over-torque.
Pr.06.04 sets the over-torque detection level, and Pr.06.05 sets
the over-torque detection time.
5
Base Block (B.B)
indication
This contact is closed when external interrupt (B.B.) occurs in
the drive and stops outputting.
6
Low-voltage indication
This contact is closed when the drive detects that the input
voltage is too low.
7
Operation mode
indication
This contact is closed when the drive operation command source
is external terminals.
8
Malfunction indication
This contact is closed when fault occurs. (oc, ov, oH1, oL, oL1,
EF, cF3.0–5, HPF1, 2, 4, ocA, ocd, ocn)
9
Desired frequency
reached
This contact is closed when the desired frequency (Pr.03.02) is
reached.
10
Terminal count value
reached
When the drive executes external counter, this contact is closed
if the count value is equal to the setting value for Pr.03.05.
11
Terminal count value
reached
When the drive executes external counter, this contact is closed
if the count value is equal to the setting value for Pr.03.06.
12
Over-voltage stall
prevention
This contact is closed when over-voltage stall prevention is ON.
13
Over-current stall
prevention
This contact is closed when the over-current stall prevention is
ON.
14
IGBT over-heating
warning
This contact is closed when IGBT overheats to prevent the drive
from shutting down due to overheating. > 85°C ON, < 80°C OFF
15
Over-voltage
This contact is closed when the drive detects that the DC bus
voltage is too high.
16
PID feedback error
This contact is closed when the PID feedback signal error is
detected. (Refer to Pr.10.08, Pr.10.12)
17
Forward command
This contact is closed when the drive operates in a forward
direction.
18
Reverse command
This contact is closed when the drive operates in a reverse
direction.
