Denon AVR-1909 Service Manual

106
AVR-1909/789, AVC-1909
POWER P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC501 00D9630057806 IC KIA78R05PI
J126780500370S
IC502 00D9600195808 IC ICP-N15 J120001500030S
IC512 00D9600159501 IC KIA7805API J126780500110S
IC513 00D2631099006 IC KIA7905PI J126790500070S
IC517 00D9600174900 IC KIA7815API J126781500000S
Q501 00D9600196409 TR 2SC1740SR J5021740S0010S
Q502 00D9630121208 TR KRC107M J6020107M0010S
Q503 00D9600196409 TR 2SC1740SR J5021740S0010S
Q513 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
Q514 00D9600097304 TR KRC102M J6020102M0010S
Q515 00D9630255802 TR 2SC KTC3199Y J5023199Y0010S
Q516 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
Q517 00D9630327808 TR KTA1281Y J5001281Y0010S
Q518 00D9600097304 TR KRC102M J6020102M0010S
Q519 00D9630328001 TR 2SC KTC3209Y J5023209Y0010S
Q520 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
D501-503 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D504-507 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D508-512 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D513-520 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D523-526 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D527-534 00D9630328409 D,SWITCHING 1N4007 E3 K000400700010S
D535,536 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD501 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
ZD502 00D9630058601 D,ZENER MTZJ12B E3 K06012R044520S
ZD502 00D9630219903 D,ZENER MTZJ16B E2, EA, JP K06016R044520S
RESISTORS GROUP
R506 00D9630244305 R,METAL FILM 2.2M 0.5W E3
C060022564520S
R507 00D2412376964 R,METAL 47-J,1/4W-R C060047063050S
R511,512 00D9630337908 R,METAL FILM 33-J,1W C060033065050S
R516-519 00D9630216003 R,METAL 0.22-J,1W-R C060R22065050S
R521 00D9630048103 R,METAL 150-J,1W-R C060015165050S
CAPACITORS GROUP
C501 00D9630234205 C,ELECT 10UF-M/50V E3
D040100087070S
C501 963134001860S C,ELECT 470UF-M/16V E2, EA, JP D040471083080S
C502 00D9630217002 C,ELECT 3300UF-M/16V AVR1909, 789EA, AVC1909 D040332083010S
C503 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C504 00D9630323802 C,CERAMIC AC(SAFETY)
0.0047UF 250VAC
D00847208H010S
C505 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C506,507 963134001820S C,ELECT 1000UF-M/35V D040102085030S
C511,512 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) E3 D040010087150S
C511,512 00D9630276409 C,ELECT 100UF-M/16V E2, EA, JP D040101083090S
C513 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C514 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) E3 D040010087150S
C514 00D9630276409 C,ELECT 100UF-M/16V E2, EA, JP D040101083090S
C515,516 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
