Denon AVR-1909 Service Manual

35
AVR-1909/789, AVC-1909
LEVEL DIAGRAMS (2/5)
CENTER LEVEL DIAGRAM
㧗
㧗
D/A OUT
MUTE
EXT IN
+20dB
+10dB
˴0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
˴0dB
-20dB
-30dB
-40dB
-10dB
LINE IN/EXT IN
0dBFS
0.88Vrms
AVR-1909
LEVEL DIAGRAM
CENTER ch
-2dB
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
-20dBFS(DIG.IN)
PCM or DD Config1
-22dBFS(A/D IN)
200mV
㧗
SPEAKER
OUT
+30dB
SP OUT
3.99Vrms/8Ω
+29dB
R2A15215FP
-2+2=0dB
NON CLICP MAX SIGNAL LEVEL 4.0Vrms
Config2˴D OLBY LIMIT LEVEL (ALLch-3dBFS)
+7dB
㧙
-26.5dBFS(DIG.IN)
˴DD Config2
GAIN
ADJ.
-2+6.5=4.5dB
Config1˴D OLBY LIMIT LEVEL (ALLch-3dBFS)
A/D
㧙
㧗
D/A
DSP
ADAU1328

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
