Denon AVR-1909 Service Manual

28
AVR-1909/789, AVC-1909
2.2. HDMI out
HDMI OUT output NG
※ When checking operation, select
DVD for the function.
(COMPONENT1 input)
Checking the video convert ON/OFF settings
Video convert ON
Input
CVBS
Input
S
Input
COMPONENT
Input
HDMI
D
To troubleshooting of
HDMI/DVI
Input 1080p? No output
E
2.2. HDMIout
HDMIOUT出力 NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
(COMPONENT1入力 )
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON/OFFの設定確認
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON
入力
CVBS
入力
S
入力
COMPONENT
入力
HDMI
Dへ
HDMI/DVI の
ﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
1080p 入力 ? 出力されません
Eへ
YES
YES

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
