Denon AVR-1909 Service Manual

125
AVR-1909/789, AVC-1909
REG P.W.B. UNIT ASS'Y
OTHERS PARTS GROUP
CN201 nsp CN,WIRE 3P
L000161030060S
CN401B nsp CN,WIRE 4P L000131040051S
CN1001 nsp CN,WIRE 11P L000121110041S
CP102B nsp CN.WAFER 3P L102526700300S
CP201 nsp CN.WAFER 6P L101200100610S
CP705 nsp CN.WAFER 3P L101200100310S
L401SBL 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L401SBR 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
TP401,402 nsp CN.WAFER 3P ANGLE L101530150310S
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC511 00D2631163000 IC KIA78R09PI
J126780900180S
IC514 00D9600159501 IC KIA7805API J126780500110S
IC515 00D9600174900 IC KIA7815API J126781500000S
IC516 00D9630021502 IC KIA7915PI J126791500030S
Q511 00D9630327905 TR KTB778 J501778000010S
Q512 00D9630328205 TR KTD998 J503998000010S
Q2015 00D9630327905 TR KTB778 J501778000010S
D521,522 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D523 00D9630236504 D,SWITCHING AX-52 K120072140010S
D537 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D539 00D9630236504 D,SWITCHING AX-52 K120072140010S
ZD503,504 00D9600096004 D,ZENER MTZJ33B K06033R044520S
CAPACITORS GROUP
C526,527 00D9609010133 C,ELECT 220UF-M/35V E3
D040221085060S
C526,527 00D2544580712 C,ELECT 100UF-M/50V E2, EA, JP D040101087150S
OTHERS PARTS GROUP
CN501 nsp CN.WAFER 10P
L101100031010S
CN508 nsp CN,WIRE 4P L000600040080S
CN509 nsp CN,WIRE 3P L000600030020S
CN2007 nsp CN,WIRE 3P L000800030170S
CP502 nsp CN.WAFER 3P L101200100310S
CP507 nsp CN.WAFER 3P L101200100310S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
