Denon AVR-1909 Service Manual

129
AVR-1909/789, AVC-1909
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に"nsp" と記載されている基板 ASS'Y は供給できません。基板 ASS'Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
BKE3 : U.S.A. & Canada model (Black model) BKEA : Australia model (Black model)
BKE2 : Europe model (Black model) SPE2 : Europe model (Premium Silver model)
BKJP(AVC1909) : Japan model (Black model) SPJP(AVC1909) : Japan model (Premium Silver model)
Ref. No. Part Name Remarks Q'ty New
BM1 nsp MAIN P.W.B. UNIT ASSY AVR1909BKE3 7025HK0804010 1
BM1 nsp MAIN P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804060 1
BM1 nsp MAIN P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804050 1
BM1 nsp MAIN P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804020 1
BM1 nsp MAIN P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804040 1
BM1 nsp MAIN P.W.B. UNIT ASSY
AVC1909JP 7025HK0804030 1
BI1 nsp INPUT P.W.B. UNIT ASSY
AVR1909BKE3 7025HK0804011 1
BI1 nsp INPUT P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804061 1
BI1 nsp INPUT P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804051 1
BI1 nsp INPUT P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804021 1
BI1 nsp INPUT P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804041 1
BI1 nsp INPUT P.W.B. UNIT ASSY
AVC1909JP 7025HK0804031 1
BF nsp FRONT P.W.B. UNIT ASSY
AVR1909BKE3 7025HK0804012 1
BF nsp FRONT P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804062 1
BF nsp FRONT P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804052 1
BF nsp FRONT P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804022 1
BF nsp FRONT P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804042 1
BF nsp FRONT P.W.B. UNIT ASSY
AVC1909JP 7025HK0804032 1
BF1 - FRONT UNIT
BF2 - V.AUX UNIT
BF3 - MIC UNIT
BF4 - FUNCTION UNIT
BF5 - SPK UNIT
BF6 - H/P UNIT
BF7 - P/S UNIT
BF8 - ENCODER UNIT
BF9 - ENCODER CNT UNIT
BP nsp POWER P.W.B. UNIT ASSY
AVR1909BKE3 7025HK0804013 1
BP nsp POWER P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804063 1
BP nsp POWER P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804053 1
BP nsp POWER P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804023 1
BP nsp POWER P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804043 1
BP nsp POWER P.W.B. UNIT ASSY
AVC1909JP 7025HK0804033 1
BP1 - POWER UNIT
BP2 - SUPPLY UNIT
BP3 - GUIDE_L UNIT
BP4 - GUIDE_R UNIT
BP5 - CNT1 UNIT
BP6 - CNT2 UNIT
BP7 - CNT3 UNIT
BP8 - CNT4 UNIT

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
