Denon AVR-1911 Service Manual

115
TCC8600 Pin Description in Pin Number Order
Doc. No AS-C-8600X-EA
TCC8600-00X-EAR
Rev. No 2.0
32-bit RISC Microprocessor for Host Player
Page 10 of 30
TELECHIPS Inc.
www.telechips.com
Signal Name Pin# Type Description – TCC8600
VDDI 58 PWR Digital Power for Internal Core (1.8V)
VDDI 91 PWR Digital Power for Internal Core (1.8V)
VDDI 110 PWR Digital Power for Internal Core (1.8V)
VDDI 124 PWR Digital Power for Internal Core (1.8V)
VDDADC 69 PWR Analog Power for ADC (3.3V)
VDDPLL 74 PWR Analog & Digital Power for PLL (1.8V)
VDDPLL1 73 PWR Analog & Digital Power for PLL1 (1.8V)
VSS 1 GND Digital Ground
VSS 8 GND Digital Ground
VSS 25 GND Digital Ground
VSS 45 GND Digital Ground
VSS 59 GND Digital Ground
VSS 81 GND Digital Ground
VSS 97 GND Digital Ground
VSS 118 GND Digital Ground
VSSADC 70 GND Analog Ground for ADC
VSSPLL 76 GND Analog Ground for PLL
VSSPLL1 71 GND Analog Ground for PLL
Table 2.2 TCC8600 Pin Description in Pin Number Order
Pin# Signal Name Type Description – TCC8600
1 VSS GND Digital Ground
2 XD[4] I/O External Bus Data Bit [4]. Internal pull-up resistor enabled at reset.
3 XD[5] I/O External Bus Data Bit [5]. Internal pull-up resistor enabled at reset.
4 XD[6] I/O External Bus Data Bit [6]. Internal pull-up resistor enabled at reset.
5 XD[7] I/O External Bus Data Bit [7]. Internal pull-up resistor enabled at reset.
6 XD[8] I/O External Bus Data Bit [8]. Internal pull-up resistor enabled at reset.
7 VDDI PWR Digital Power for Internal Core (1.8V)
8 VSS GND Digital Ground
9 VDDIO PWR Digital Power for I/O (3.3V)
10 XD[9] I/O External Bus Data Bit [9]. Internal pull-up resistor enabled at reset.
11 XD[10] I/O External Bus Data Bit [10]. Internal pull-up resistor enabled at reset.
12 XD[11] I/O External Bus Data Bit [11]. Internal pull-up resistor enabled at reset.
13 XD[12] I/O External Bus Data Bit [12]. Internal pull-up resistor enabled at reset.
14 XD[13] I/O External Bus Data Bit [13]. Internal pull-up resistor enabled at reset.
15 XD[14] I/O External Bus Data Bit [14]. Internal pull-up resistor enabled at reset.
16 XD[15] I/O External Bus Data Bit [15]. Internal pull-up resistor enabled at reset.
17 XA[0] I/O External Bus Address Bit [0]
18 XA[1] I/O External Bus Address Bit [1]
19 XA[2] I/O External Bus Address Bit [2]
20 XA[3] I/O External Bus Address Bit [3]
21 XA[4] I/O External Bus Address Bit [4]
22 XA[5] I/O External Bus Address Bit [5]
23 XA[6] I/O External Bus Address Bit [6]
24 VDDI PWR Digital Power for Internal Core (1.8V)
25 VSS GND Digital Ground
26 VDDIO PWR Digital Power for I/O (3.3V)
27 XA[7] I/O External Bus Address Bit [7]
28 XA[8] I/O External Bus Address Bit [8]
29 XA[9] I/O External Bus Address Bit [9]
30 XA[10] I/O External Bus Address Bit [10]
31 XA[11] I/O External Bus Address Bit [11]
32 XA[12] I/O External Bus Address Bit [12]
33 XA[13] / SD_BA[0] I/O External Bus Address Bit [13] / SDRAM Bank Address 0.
34 XA[14] / SD_BA[1] I/O External Bus Address Bit [14] / SDRAM Bank Address 1
35 XA[15] / SD_nCAS I/O External Bus Address Bit [15] / SDRAM CAS signal
Doc. No AS-C-8600X-EA
TCC8600-00X-EAR
Rev. No 2.0
32-bit RISC Microprocessor for Host Player
Page 10 of 30
TELECHIPS Inc.
www.telechips.com
Signal Name Pin# Type Description – TCC8600
VDDI 58 PWR Digital Power for Internal Core (1.8V)
VDDI 91 PWR Digital Power for Internal Core (1.8V)
VDDI 110 PWR Digital Power for Internal Core (1.8V)
VDDI 124 PWR Digital Power for Internal Core (1.8V)
VDDADC 69 PWR Analog Power for ADC (3.3V)
VDDPLL 74 PWR Analog & Digital Power for PLL (1.8V)
VDDPLL1 73 PWR Analog & Digital Power for PLL1 (1.8V)
VSS 1 GND Digital Ground
VSS 8 GND Digital Ground
VSS 25 GND Digital Ground
VSS 45 GND Digital Ground
VSS 59 GND Digital Ground
VSS 81 GND Digital Ground
VSS 97 GND Digital Ground
VSS 118 GND Digital Ground
VSSADC 70 GND Analog Ground for ADC
VSSPLL 76 GND Analog Ground for PLL
VSSPLL1 71 GND Analog Ground for PLL
Table 2.2 TCC8600 Pin Description in Pin Number Order
Pin# Signal Name Type Description – TCC8600
1 VSS GND Digital Ground
2 XD[4] I/O External Bus Data Bit [4]. Internal pull-up resistor enabled at reset.
3 XD[5] I/O External Bus Data Bit [5]. Internal pull-up resistor enabled at reset.
4 XD[6] I/O External Bus Data Bit [6]. Internal pull-up resistor enabled at reset.
5 XD[7] I/O External Bus Data Bit [7]. Internal pull-up resistor enabled at reset.
6 XD[8] I/O External Bus Data Bit [8]. Internal pull-up resistor enabled at reset.
7 VDDI PWR Digital Power for Internal Core (1.8V)
8 VSS GND Digital Ground
9 VDDIO PWR Digital Power for I/O (3.3V)
10 XD[9] I/O External Bus Data Bit [9]. Internal pull-up resistor enabled at reset.
11 XD[10] I/O External Bus Data Bit [10]. Internal pull-up resistor enabled at reset.
12 XD[11] I/O External Bus Data Bit [11]. Internal pull-up resistor enabled at reset.
13 XD[12] I/O External Bus Data Bit [12]. Internal pull-up resistor enabled at reset.
14 XD[13] I/O External Bus Data Bit [13]. Internal pull-up resistor enabled at reset.
15 XD[14] I/O External Bus Data Bit [14]. Internal pull-up resistor enabled at reset.
16 XD[15] I/O External Bus Data Bit [15]. Internal pull-up resistor enabled at reset.
17 XA[0] I/O External Bus Address Bit [0]
18 XA[1] I/O External Bus Address Bit [1]
19 XA[2] I/O External Bus Address Bit [2]
20 XA[3] I/O External Bus Address Bit [3]
21 XA[4] I/O External Bus Address Bit [4]
22 XA[5] I/O External Bus Address Bit [5]
23 XA[6] I/O External Bus Address Bit [6]
24 VDDI PWR Digital Power for Internal Core (1.8V)
25 VSS GND Digital Ground
26 VDDIO PWR Digital Power for I/O (3.3V)
27 XA[7] I/O External Bus Address Bit [7]
28 XA[8] I/O External Bus Address Bit [8]
29 XA[9] I/O External Bus Address Bit [9]
30 XA[10] I/O External Bus Address Bit [10]
31 XA[11] I/O External Bus Address Bit [11]
32 XA[12] I/O External Bus Address Bit [12]
33 XA[13] / SD_BA[0] I/O External Bus Address Bit [13] / SDRAM Bank Address 0.
34 XA[14] / SD_BA[1] I/O External Bus Address Bit [14] / SDRAM Bank Address 1
35 XA[15] / SD_nCAS I/O External Bus Address Bit [15] / SDRAM CAS signal

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
