Denon AVR-1911 Service Manual

127
PARTS LIST OF P.C.B. UNIT
s
zParts for which "nsp" is indicated on this table cannot be supplied.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
1911E3 : U.S.A. & Canada model 1911E2 : Europe model 1911E1C : China model
791E3 : U.S.A. & Canada model 791EA : Australia model
BK : Black model SP : Premium Silver model
PCB 7CH_AMP ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q401 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q403 00D2710318909 TR 2SA 2N5401S J520254010010S
Q405 00D2710318909 TR 2SA 2N5401S J520254010010S
Q406 00D2730479909 TR 2SC 2N5551S J522255510010S
Q407,408 00D9600196302 TR KTA1268BL J5001268B0050S
Q412 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q413 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q415 00D2710318909 TR 2SA 2N5401S J520254010010S
Q417 00D9600196302 TR KTA1268BL J5001268B0050S
Q418 00D2730479909 TR 2SC 2N5551S J522255510010S
Q419,420 00D9600196302 TR KTA1268BL J5001268B0050S
Q424 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q425 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q427 00D2710318909 TR 2SA 2N5401S J520254010010S
Q430 00D2730479909 TR 2SC 2N5551S J522255510010S
Q431,432 00D9600196302 TR KTA1268BL J5001268B0050S
Q436 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q437 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q439 00D2710318909 TR 2SA 2N5401S J520254010010S
Q442 00D2730479909 TR 2SC 2N5551S J522255510010S
Q443,444 00D9600196302 TR KTA1268BL J5001268B0050S
Q448 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q449 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q451 00D2710318909 TR 2SA 2N5401S J520254010010S
Q454 00D2730479909 TR 2SC 2N5551S J522255510010S
Q455,456 00D9600196302 TR KTA1268BL J5001268B0050S
Q460 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q461 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q463 00D2710318909 TR 2SA 2N5401S J520254010010S
Q466 00D2730479909 TR 2SC 2N5551S J522255510010S
Q467,468 00D9600196302 TR KTA1268BL J5001268B0050S
Q472 00D2730471907 TR 2SC KTC3206Y
J5023206Y0050S
Q473 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q475 00D2710318909 TR 2SA 2N5401S J520254010010S
Q478 00D2730479909 TR 2SC 2N5551S J522255510010S
Q479,480 00D9600196302 TR KTA1268BL J5001268B0050S
Q484 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
D402-404 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D408-410 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D414-416 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D420-422 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D426-428 00D2760401905 D,SWITCHING 1SS133T K000013300520S

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
