Denon AVR-1911 Service Manual

140
PCB AUDIO_VIDEO ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC801 235810045600S IC R2A15220FP J084152200010S *
IC804 00D2623446900 IC TC4052BFT J040405201010S
IC805 232810005504S IC BD7628F-E2 J127762800010S
IC806 963239010400S IC MM74HC4053MTC J040744053050S
IC807,808 232810005504S IC BD7628F-E2 J127762800010S
IC809 00D2623445901 IC TC4051BFT J040405101010S
IC810 00D9630116307 IC LC74781-9013-E J170747810010S
IC811 963239003470S IC NJM2586AM J171258600010S
Q815 00D9630044301 TR KTC2875B(MB) 1911E2,1911E1C,791EA J5222875B0010S
Q816,817 00D9630120704 TR KRA102S(PB) 1911BKE3 J520010200210S
Q815 00D9630044301 TR KTC2875B(MB) 1911E2,1911E1C,791EA J5222875B0010S
Q821 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q822,823 00D9630120704 TR KRA102S(PB) J520010200210S
Q824-825 963219010760S TR KRC231(NW) J5220231M0010S
Q826 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q827 963219010740S TR KRA111S J520011100210S
Q828 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q829,830 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q831 00D2710305909 SEMI KTA1504S J520015040150S
Q832,833 00D9630121509 TR KTC3875S J522038750210S
Q834 00D2710305909 SEMI KTA1504S J520015040150S
Q838 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q839 00D2710305909 SEMI KTA1504S J520015040150S
Q840 00D9630121606 TR KRC107S (NH) J522107S00210S
Q841 00D9630120801 TR 2SC KRC102S (NB) 1911E3 J522010200210S
Q842 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
D800,801 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D826 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D828,829 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D833,834 963209003510S D,ESD CDS3C05HDMI1 K067030500010S
D837 963209003510S
D,ESD CDS3C05HDMI1 K067030500010S
D838-843 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD800 00D2760760905 D,ZENER MTZJ3.6B-0.5W/5MA K06003R644520S
CAPACITORS GROUP
C800-807 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C808 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C809,810 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C811 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C812,813 nsp C,CERAMIC 330PF-J/50V D010331167160S
C826 nsp C,CERAMIC 330PF-J/50V D010331167160S
C828 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C829 nsp C,CERAMIC 330PF-J/50V D010331167160S
C830 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C831 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C832 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C833 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C834 nsp C,CERAMIC 330PF-J/50V D010331167160S
C835,836 00D9630293709 C,ELECT 100UF-M/10V D040101082070S

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
