58
AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
CPU P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC202 00D 963 0354 907 MAIN CPU SUB ASSY(V0.67) M30626(2307-M) *
IC203 00D 963 0147 606 IC KIA78R09API J126780900120S
IC204 00D 960 0159 501 IC KIA7805API J126780500110S
IC205 00D 963 0327 507 IC KIA7905PI J126790500070S *
IC206 00D 963 0326 906 IC LC72722PM E2,E2A J124727220010S *
IC207 00D 963 0327 400 IC KIA7809API J126780900020S *
IC361 00D 963 0237 503 IC JSR1165-C E100116500040S
Q201 00D 963 0121 509 TR KTC3875S J522038750210S
Q202 00D 960 0285 006 TR KRC104S J522104S00210S
Q203 00D 963 0120 801 TR KRC102S J522010200210S
Q204 00D 963 0328 001 TR KTC3209Y J5023209Y0010S *
Q205-208 00D 963 0044 301 TR KTC2875B 2307CIE3,887E3 J5222875B0010S
Q209 00D 963 0120 801 TR KRC102S J522010200210S
Q210 00D 963 0328 205 TR KTD998 J503998000010S *
Q261,262 00D 963 0327 808 TR KTA1281Y J5001281Y0010S *
Q263 00D 963 0148 508 TR KTA1504S J520015040150S
Q264 00D 963 0327 905 TR KTB778 J501778000010S *
Q302 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q316 00D 963 0121 402 TR KRA104S J520010400210S
Q320 00D 963 0148 508 TR KTA1504S J520015040150S
Q321 00D 275 0110 905 TR 2SA933S J5000933S0050S
Q322 00D 963 0121 208 TR KRC107M J6020107M0010S
Q323 00D 963 0148 508 TR KTA1504S J520015040150S
Q324,325 00D 963 0120 801 TR KRC102S J522010200210S
D201 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S *
D202 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D203,204 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
D205-207 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D208,209 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
D303-305 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D306-309 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
ZD201 00D 963 0047 502 D,ZENER MTZJ3.3B K06003R344520S
ZD301 00D 960 0095 801 D,ZENER MTZJ6.8B K06006R844520S
RESISTORS GROUP
R205 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R271,272 - R,METAL FILM 33-J,1W C060033065050S
R224 - CN,WIRE 1P 887E3 L045084006040S
R237 - CN,WIRE 1P 2307CIE3 L045084006040S
CAPACITORS GROUP
C202 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C203 00D 963 0311 607 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C204 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C205,206 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C208-213 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C214 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C215 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C216 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C217 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C218,219 00D 963 9004 614 C,CERAMIC 27PF-J/50V E2,E2A D010270167160S
C220 00D 963 0234 205 C,ELECT 10UF-M/50V E2,E2A D040100087070S
C221 00D 963 9005 862 C,ELECT 47UF-M/16V E2,E2A D040470083080S
C223,224 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C225 nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V E2,E2A D010561167160S
C226 - C,CERAMIC 330PF-J/50V D010331167160S
C227 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C228 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
