COMPONENT P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1301 00D 262 3551 002 IC NJW1321FP1 J171132100010S
IC1302,1303 00D 963 0327 604 IC NJM2581M J127258100010S *
D1317,1318 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
CAPACITORS GROUP
C1301-1309 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1310-1318 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1319-1321 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1322 - C,ELECT 100UF-M/16V D040101083070S
C1323-1328 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1329-1331 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1332 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1333,1334 - C,ELECT 100UF-M/16V D040101083070S
C1335 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1336 - C,ELECT 100UF-M/16V D040101083070S
C1337 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1338 - C,ELECT 100UF-M/16V D040101083070S
C1339 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1340 - C,ELECT 100UF-M/16V D040101083070S
C1341 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1342 - C,ELECT 100UF-M/16V D040101083070S
C1343 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1344 - C,ELECT 100UF-M/16V D040101083070S
C1345 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1346 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C1347 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1348-1350 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1351 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S *
C1352-1354 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1355 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S *
C1356 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C1358 nsp 00D 963 0233 604 C,CERAMIC 220PF-J/50V D010221167160S
C1359-1362 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1363 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S *
C1364-1366 nsp 00D 960 9010 094 C,CERAMIC 0.01UF-Z/50V D011103597160S
C1367 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S *
C1368 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C1369,1370 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
OTHERS PARTS GROUP
CN1303 nsp 00D 963 0110 701 CN.WAFER 14P L101100031410S
CN1304 nsp 00D 963 0097 206 CN.WAFER 8P L101100030810S
CP3001B 00D 963 0330 701 CN.FPC 18P L130211800010S *
JACK1301,
1302
00D 963 0146 306 TER,RCA 6PIN G603603B2600YS
TR1301 00D 963 0120 801 TR KRC102S J522010200210S
TR1302 00D 963 0121 606 TR KRC107S J522107S00210S
TR1303 00D 963 0148 508 TR KTA1504S J520015040150S
5
