AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
2CH-AMP P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101H 00D 963 0313 702 IC BA033T/3.3V J12603R300010S
IC102X 00D 963 0327 206 IC BA50BC0T J126050000040S *
IC103H 00D 963 0327 905 TR KTB778 J501778000010S *
IC103X 00D 263 1223 005 PQ20RX11J00H 2307CIE3,887E3 J126201100010S
Q101H 00D 963 0327 808 TR KTA1281Y J5001281Y0010S *
Q101SBL 00D 963 0235 301 TR 2SD2560Y J5032560Y0170S
Q101SBR 00D 963 0235 301 TR 2SD2560Y J5032560Y0170S
Q101X 00D 963 0120 801 TR KRC102S 2307CIE3,887E3 J522010200210S
Q102H 00D 963 0121 606 TR KRC107S J522107S00210S
Q102SBL 00D 963 0235 204 TR 2SB1647Y J5011647Y0170S
Q102SBR 00D 963 0235 204 TR 2SB1647Y J5011647Y0170S
Q102X 00D 963 0120 801 TR KRC102S 2307CIE3,887E3 J522010200210S
Q103SBL 00D 963 0280 107 TR 2SC3964 J502396400000S
Q103SBR 00D 963 0280 107 TR 2SC3964 J502396400000S
Q104SBL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q104SBR 00D 960 0196 506 TR KSC1845F J5021845F0000S
D100X 00D 960 0197 107 D,RECTIFIER BRIDGE KBPC604 6A K047604000020S
D101SBL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101SBR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102SBL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102SBR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D106,107 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
ZD101H 00D 960 0095 704 D,ZENER MTZJ6.2B K06006R244520S
ZD101SBL 00D 276 0843 903 HZS3C-3(52mm) K06003R37Z520S
ZD101SBR 00D 276 0843 903 HZS3C-3(52mm) K06003R37Z520S
ZD102SBL 00D 276 0844 902 HZS3B-3(52mm) K06003R36Z520S
ZD102SBR 00D 276 0844 902 HZS3B-3(52mm) K06003R36Z520S
RESISTORS GROUP
R104SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105H - R,METAL FILM 33-J,1W C060033065050S
R105SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R106SBL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106SBR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107SBL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107SBR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R108SBL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R108SBR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R109SBL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R109SBR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R110SBL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R110SBR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R111SBL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R111SBR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R118SBL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R118SBR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R119SBL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R119SBR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
VR106,107 00D 963 0105 208 VR,SEMI 1KB RH063LC13R C544102015140S
CAPACITORS GROUP
C101H 00D 963 0255 501 C,ELECT 18000UF-M/16V D040183083000S
C101SBL 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070S
C101SBR 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070S
C101X 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
