AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
S-C VIDEO P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1001,1002 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1005,1006 00D 963 0326 207 IC BU4051BCFV J040405100040S *
IC1007 00D 963 0326 401 IC BU4053BCFV-E2 J040405300160S *
IC1008 00D 963 0326 304 IC BU4052BCFV J040405200070S *
IC1009 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1104,1105 00D 963 0326 207 IC BU4051BCFV J040405100040S *
IC1106-1108 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1109,1110 00D 963 0326 207 IC BU4051BCFV J040405100040S *
IC1111,1112 00D 963 0326 401 IC BU4053BCFV-E2 J040405300160S *
IC1113 00D 963 0326 304 IC BU4052BCFV J040405200070S *
IC1116,1117 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1118 00D 262 2827 902 MM74HC4053SJ +C J040744053060S
IC1119,1120 00D 963 0326 100 IC BU4094BCFV J040140940040S *
IC1121 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1123 00D 262 3450 006 M35015-***SP J170350150010S
IC1124 00D 963 0326 401 IC BU4053BCFV-E2 J040405300160S *
IC1125 00D 963 0326 100 IC BU4094BCFV J040140940040S *
IC1126 00D 963 0327 701 IC NJM2229M J170222900010S *
IC1127 00D 963 0326 100 IC BU4094BCFV JP J040140940040S *
IC1128,1129 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1130 00D 963 0300 702 IC LM1117S J126111733030S
IC1131 00D 263 1205 900 PQ012FZ01ZP +C J126012010010S
Q1101,1102 00D 963 0328 302 TR KTC3875G J5223875G0210S *
D1001,1002 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
D1101-1103 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
D1105 00D 963 0328 506 D,SWITCHING KDS184S(B3) K005018400020S *
CAPACITORS GROUP
C1007-1010 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1013-1016 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S *
C1017-1024 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1025,1026 - C,ELECT 100UF-M/16V D040101083070S
C1027 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C1028 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1029 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C1030 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1031,1032 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1033 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C1034 00D 963 0324 500 C,ELECT 330UF-M/6.3V D040331081060S *
C1035 00D 257 2015 903 CS77B1A100MT D070100082301S
C1036,1037 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C1038 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1039 00D 963 0324 500 C,ELECT 330UF-M/6.3V D040331081060S *
C1040 00D 257 2015 903 CS77B1A100MT D070100082301S
C1041,1042 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1043 00D 963 0324 500 C,ELECT 330UF-M/6.3V D040331081060S *
C1044 00D 257 2015 903 CS77B1A100MT D070100082301S
C1071-1074 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C1075 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1107-1116 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1119-1122 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1125-1130 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1131-1134 - C,ELECT 100UF-M/16V D040101083070S
C1135 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C1136 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1137 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C1138 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C1139-1142 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C1143 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C1146,1147 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
