AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
2307CIE3 : U.S.A. & Canada model (AVR-2307CI)(Black) 887E3 : U.S.A. & Canada model (AVR-887)(Black)
BKE2 : Europe model (Black) SRE2 : Europe model (Silver)
E2A : Asia model(Premium Silver) EUT : Taiwan R.O.C. model(Premium Silver)
E1C : China model(Premium Silver) JP : Japan model (AVC-1930)(Premium Silver)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
39A 00D 963 0319 900 MAIN P.W.B. ASSY 2307CIE3,887E3 7025HK0513010 1 *
39A 00D 963 0321 105 MAIN P.W.B. ASSY E2,E2A 7025HK0513030 1 *
39A 00D 963 0321 804 MAIN P.W.B. ASSY EUT 7025HK0513060 1 *
39A 00D 963 0322 308 MAIN P.W.B. ASSY E1C 7025HK0513070 1 *
39A 00D 963 0322 609 MAIN P.W.B. ASSY JP 7025HK0513080 1 *
13 POWER S/W P.W.B.
15 HEADPHONE P.W.B.
39 MAIN P.W.B.
45 AC OUTLET P.W.B.
31A 00D 963 0320 009 CPU P.W.B. ASSY 2307CIE3 7025HK0513011 1 *
31A 00D 963 0320 805 CPU P.W.B. ASSY 887E3 7025HK0513021 1 *
31A 00D 963 0321 202 CPU P.W.B. ASSY E2,E2A 7025HK0513031 1 *
31A 00D 963 0321 901 CPU P.W.B. ASSY EUT 7025HK0513061 1 *
31A 00D 963 0322 405 CPU P.W.B. ASSY E1C 7025HK0513071 1 *
31A 00D 963 0322 706 CPU P.W.B. ASSY JP 7025HK0513081 1 *
17 FRONT S-VIDEO P.W.B. 7028064875010
18 FRONT V-AUX P.W.B. 7028064873010
19 FR OPTICAL P.W.B. 7028064874010
21 FRONT P.W.B. 7028064872010
31 CPU P.W.B. 7028064871010
30A 00D 963 0320 106 CNT P.W.B. ASSY 2307CIE3 7025HK0513012 1 *
30A 00D 963 0320 902 CNT P.W.B. ASSY 887E3 7025HK0513022 1 *
30A 00D 963 0321 309 CNT P.W.B. ASSY E2,E2A 7025HK0513032 1 *
30A 00D 963 0322 007 CNT P.W.B. ASSY EUT 7025HK0513062 1 *
30A 00D 963 0322 502 CNT P.W.B. ASSY E1C 7025HK0513072 1 *
30A 00D 963 0322 803 CNT P.W.B. ASSY JP 7025HK0513082 1 *
30 CNT P.W.B. 7028064881010
40 PREAMP P.W.B. 7028064882010
44 UP-CNT1 P.W.B. 7028064883010
75 UP-CNT2 P.W.B. 7028064884010
76 UP-CNT3 P.W.B. 7028064885010
12A 00D 963 0320 203 OPTICAL P.W.B. ASSY 2307CIE3 7025HK0513013 1 *
12A 00D 963 0320 902 OPTICAL P.W.B. ASSY 887E3 7025HK0513022 1 *
12A 00D 963 0321 406 OPTICAL P.W.B. ASSY E2,E2A 7025HK0513033 1 *
12A 00D 963 0322 104 OPTICAL P.W.B. ASSY EUT 7025HK0513063 1 *
12A 00D 963 0322 900 OPTICAL P.W.B. ASSY E1C,JP 7025HK0513083 1 *
12 ENCODER P.W.B. 7028064894010
32 PHONO P.W.B. 7028064892010
35 OPTICAL P.W.B. 7028064891010
42 PREOUT P.W.B. 7028064893010
37A 00D 963 0320 407 INPUT P.W.B. ASSY 2307CIE3 7025HK0513015 1 *
37A 00D 963 0321 008 INPUT P.W.B. ASSY 887E3 7025HK0513025 1 *
37A 00D 963 0321 600 INPUT P.W.B. ASSY E2,E2A,EUT 7025HK0513035 1 *
37A 00D 963 0322 201 INPUT P.W.B. ASSY E1C 7025HK0513065 1 *
37A 00D 963 0323 103 INPUT P.W.B. ASSY JP 7025HK0513085 1 *
37 INPUT P.W.B. 7028064911010
20 MIC P.W.B. 7028064912010
43 VERTICAL CNT1 P.W.B. 7028064913010
74 VERTICAL CNT2 P.W.B. 7028064914010
