AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
INPUT P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201T 00D 262 3567 009 TC94A27BUG(BR-DRY) J084942700010S
IC202T 00D 262 3567 009 TC94A27BUG(BR-DRY) J084942700010S
IC203T 00D 963 0326 508 IC NJU7313AL J040731300010S *
IC204T 00D 963 0326 508 IC NJU7313AL J040731300010S *
IC205-207 00D 963 0202 305 IC NJM2068M J121206800020S
IC208-211 00D 963 0159 005 IC NJM5532M J121553200030S
IC701 00D 262 3568 008 TC9274CNG-011 J040927400030S
IC701M 00D 963 0202 305 IC NJM2068M J121206800020S
IC702 00D 963 0202 305 IC NJM2068M J121206800020S
IC705 00D 262 3566 000 TC9273CNG-004 J040927300010S
IC707,708 00D 963 0202 305 IC NJM2068M 2307CIE3,887E3,
E2,E2A,EUT
J121206800020S
Q207T 00D 960 0196 807 TR 2SK117Y (TYPE2) J5441170Y0050S
Q208T 00D 960 0196 807 TR 2SK117Y (TYPE2) J5441170Y0050S
Q209T 00D 960 0097 003 TR KRA104M J6000104M0010S
Q210T 00D 963 0121 004 TR KRC104M J502104000010S
Q1208-1211 00D 963 0044 301 TR KTC2875B 2307CIE3 J5222875B0010S
D205T 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
D207T 00D 960 0197 000 D,SWITCHING KDS160(UF) K005016000010S
D231SL 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
ZD701M 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
RESISTORS GROUP
R229T 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R230T 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
CAPACITORS GROUP
C211SW nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C212SW nsp 00D 963 0233 808 C,CERAMIC 47PF-J/50V D010470167160S
C213FL nsp 00D 963 9004 591 C,CERAMIC 22PF-J/50V D010220167160S
C213FR nsp 00D 963 9004 591 C,CERAMIC 22PF-J/50V D010220167160S
C213T 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C214T 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C215T 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C216T 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C217T 00D 963 9010 641 C,CERAMIC 0.047UF-K/16V D011473773160S
C218FL nsp 00D 963 0223 805 C,CERAMIC 33PF-J/50V D010330167160S
C218FR nsp 00D 963 0223 805 C,CERAMIC 33PF-J/50V D010330167160S
C218T 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C219FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C219FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C219SW 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C219T 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C220T 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C221FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C221FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C222SW 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C223C 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C223FL 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C223FR 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C223SBL 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C223SBR 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C223SL 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C223SR 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C223SW 00D 963 0312 004 C,ELECT 22UF-M/25V D040220084050S
C225T 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C226T 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C227T 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
