AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
CNT P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC551-553 00D 963 0218 807 IC BU4094BCF J040140940030S
IC554 00D 963 0313 702 IC BA033T/3.3V J12603R300010S
Q501C 00D 960 0196 603 TR KTC2874B J502287400010S
Q501FL 00D 960 0196 603 TR KTC2874B J502287400010S
Q501FR 00D 960 0196 603 TR KTC2874B J502287400010S
Q501SBL 00D 960 0196 603 TR KTC2874B J502287400010S
Q501SBR 00D 960 0196 603 TR KTC2874B J502287400010S
Q501SL 00D 960 0196 603 TR KTC2874B J502287400010S
Q501SR 00D 960 0196 603 TR KTC2874B J502287400010S
Q502C 00D 276 0844 902 TR KSA992F J5000992F0050S
Q502FL 00D 276 0844 902 TR KSA992F J5000992F0050S
Q502FR 00D 276 0844 902 TR KSA992F J5000992F0050S
Q502SBL 00D 276 0844 902 TR KSA992F J5000992F0050S
Q502SBR 00D 276 0844 902 TR KSA992F J5000992F0050S
Q502SL 00D 276 0844 902 TR KSA992F J5000992F0050S
Q502SR 00D 276 0843 903 TR KSA992F J5000992F0050S
Q503C 00D 276 0843 903 TR KSA992F J5000992F0050S
Q503FL 00D 276 0843 903 TR KSA992F J5000992F0050S
Q503FR 00D 276 0843 903 TR KSA992F J5000992F0050S
Q503SBL 00D 276 0843 903 TR KSA992F J5000992F0050S
Q503SBR 00D 276 0843 903 TR KSA992F J5000992F0050S
Q503SL 00D 276 0843 903 TR KSA992F J5000992F0050S
Q503SR 00D 276 0833 900 TR KSA992F J5000992F0050S
Q504C 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q504FL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q504FR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q504SBL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q504SBR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q504SL 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q504SR 00D 960 0196 506 TR KSC1845F J5021845F0000S
Q550 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q551 00D 960 0196 700 TR KTC3200BL J5023200B0050S
Q551T 00D 960 0097 003 TR KRA104M 2307CIE3 J6000104M0010S
Q552 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q552T 00D 960 0285 006 TR KRC104S 2307CIE3 J522104S00210S
Q553 00D 963 0120 704 TR KRA102S J520010200210S
Q553T 00D 960 0097 003 TR KRA104M 2307CIE3 J6000104M0010S
Q554 00D 963 0120 704 TR KRA102S J520010200210S
Q554T 00D 960 0285 006 TR KRC104S 2307CIE3 J522104S00210S
Q555 00D 963 0120 704 TR KRA102S J520010200210S
Q555T 00D 963 0255 802 TR KTC3199Y 2307CIE3 J5023199Y0010S
Q556 00D 963 0120 704 TR KRA102S J520010200210S
Q557 00D 963 0245 003 TR KRC106S J522010600210S
Q557M 00D 963 0245 003 TR KRC106S J522010600210S
Q558 00D 963 0148 508 TR KTA1504S J520015040150S
Q558M 00D 963 0148 508 TR KTA1504S J520015040150S
Q559 00D 963 0120 704 TR KRA102S J520010200210S
Q561-564 00D 963 0120 704 TR KRA102S J520010200210S
Q565 00D 963 0120 704 TR KRA102S 2307CIE3,887E3,
E2,E2A,EUT
J520010200210S
Q566 00D 963 0120 704 TR KRA102S J520010200210S
Q567 00D 963 0327 808 TR KTA1281Y J5001281Y0010S *
Q568 00D 960 0097 304 TR KRC102M J6020102M0010S
D550 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S *
D551 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D552-557 00D 963 0020 309 D,SWITCHING 1SS133T Except for JP K000013300520S
D552-557 00D 963 0236 504 RB721Q-40 JP K120072140010S
D559-561 00D 963 0020 309 D,SWITCHING 1SS133T Except for JP K000013300520S
D559-561 00D 963 0236 504 RB721Q-40 JP K120072140010S
D562-564 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S *
D565 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
