AVR-2307CI / AVR-2307 / AVR-887 / AVC-1930
HDMI P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC804 00D 262 3661 002 ADSP21266SKSTZ-2B-EC J080212660020S
IC805 00D 963 0355 003 DSP ROM SUB ASSY(V35.23)
LH28F160BJE-
BTL90
IC806 00D 262 3536 001 AS7C34096A-10TCN J001340960010S
IC807 00D 262 3066 102 LC89057W-VF4-E(AC) +REF J046890570010S
IC808 00D 262 3645 002 ADAU1328BSTZ J080132800000S
IC815A 00D 963 0043 807 IC BA4510F-E2 J121451000010S
IC816A 00D 963 0043 807 IC BA4510F-E2 J121451000010S
IC817 00D 262 3536 001 AS7C34096A-10TCN J001340960010S
IC817A 00D 963 0202 305 IC NJM2068M J121206800020S
IC818 00D 262 2642 909 SN74LV573APWR +REF J040745730200S
IC818A 00D 963 0202 305 IC NJM2068M J121206800020S
IC819 00D 262 2642 909 SN74LV573APWR +REF J040745730200S
IC819A 00D 963 0202 305 IC NJM2068M J121206800020S
IC820 00D 262 3339 907 SN74LVC139APWR +REF J040741390040S
IC820A 00D 963 0202 305 IC NJM2068M J121206800020S
IC822 00D 963 0327 303 IC KIA7805AF J126780500450S *
IC826 00D 963 0300 702 IC LM1117S J126111733030S
IC831 00D 963 0300 702 IC LM1117S J126111733030S
IC3001 00D 963 0295 309 IC LM1117S J126111718020S
IC3002 00D 963 0325 800 IC BR24L02F-W J000240200150S *
IC3003 00D 963 0295 309 IC LM1117S J126111718020S
IC3004 00D 262 3654 006 SII9033CTU J040903300010S
IC3005 00D 963 0325 800 IC BR24L02F-W J000240200150S *
IC3006 00D 262 3364 011 SII9030CTU-7 J040903000020S
IC3007,3008 00D 262 3553 000 LC4064V-75TN100C J003406400010S
IC3009 00D 963 0327 109 IC BA33BC0FP J12603R300040S *
IC3011 00D 262 3519 905 PQ018EZ01ZPH J126018010010S
IC3013 00D 963 0327 002 IC BA25BC0FP J12602R500010S *
IC3014 00D 262 3519 905 PQ018EZ01ZPH J126018010010S
IC3015 00D 262 3603 002 ADV7401BSTZ-110 J044740100010S
IC3016 00D 963 0327 002 IC BA25BC0FP J12602R500010S *
IC3017 00D 262 3478 004 ADV7320 J045732000010S
IC3018 00D 963 0295 406 IC BH7868FS J127786800000S
IC3019 00D 262 3068 003 EPM3128ATC144-10N +REF J003312800010S
IC3021 00D 262 3425 905 LTC4300-2CMS8 J040430000000S
IC3025 00D 963 0300 702 IC LM1117S 2307CIE3,887E3 J126111733030S
IC3026 00D 262 3517 907 F2602-01-TR 2307CIE3,887E3 J080260200010S
IC3027 00D 262 2813 903 SN74AHCT08PW-EL2 +C 2307CIE3,887E3 J040740800190S
IC3028 00D 262 2517 908 SN74LV08APW-EL2 +REF 2307CIE3,887E3 J040740800200S
IC3029 00D 262 2813 903 SN74AHCT08PW-EL2 +C J040740800190S
IC3030 00D 262 2517 908 SN74LV08APW-EL2 +REF J040740800200S
IC3031 00D 963 0355 100 SUB CPU SUB ASSY(V0.29) M30620FCPGP *
IC3032 00D 963 0202 305 IC NJM2068M 2307CIE3,887E3 J121206800020S
IC3033 00D 963 0327 303 IC KIA7805AF 2307CIE3,887E3 J126780500450S *
IC3034 00D 963 0294 902 IC AK4385 2307CIE3,887E3 J042438500010S
Q804C 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q804FL 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q804FR 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q804SBL 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q804SBR 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q804SL 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q804SR 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q804SW 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q808 00D 963 0120 801 TR KRC102S J522010200210S
Q809,810 00D 963 0120 704 TR KRA102S J520010200210S
Q3001-3003 00D 275 0110 905 HN1K02FU-TE85L J543102000010S
Q3004 00D 963 0120 704 TR KRA102S J520010200210S
Q3005 00D 960 0285 006 TR KRC104S J522104S00210S
Q3006 00D 963 0120 801 TR KRC102S J522010200210S
Q3007 00D 960 0285 006 TR KRC104S J522104S00210S
Q3008,3009 00D 275 0110 905 HN1K02FU-TE85L J543102000010S
Q3010 00D 963 0120 704 TR KRA102S J520010200210S
