Page #88 background imageLoading...
Page #88 background image
85
Inputting characters
You can change the names as desired using the “Preset Name”
(vpage 93), “Rename” (vpage 91), “Rhapsody Account”
(vpage 111), “Napster Account” (vpage 111), “Zone Rename”
(vpage 114), “Quick Select Name” (vpage 114) and character
input for the network functions.
For inputting characters, there are three methods, as shown below.
Method for inputting characters
Method Operations
Using the keyboard
screen
•Operating with the remote control unit.
•Select a character on the TV screen to
input characters.
Using the number
buttons
(10 Key input screen)
•Operating with the remote control unit.
•Multiple characters are assigned to
a button, and each time the button is
pressed, a character is switched.
Using the cursor buttons
(10 Key input screen)
•Operating with the remote control unit.
•Use
uio p and ENTER to input
characters.
Keyboard screen
nDisplay of a keyboard input screen
[1/2]
RENAME
BD
a/A
SPACE
INSERT DELETE O K
RETURN
InputSelect Cancel
SEARCH
10Key
SHIFT
a/A
A
N
0
$
B
O
1
%
C
P
2
&
D
Q
3
'
E
R
4
(
F
S
5
)
G
T
6
*
H
U
7
+
I
V
8
,
J
W
9
;
K
X
!
<
L
Y
"
=
M
Z
#
>
BD
q
w
e
r
Q0
t
y
u o
i
q Character input section (Maximum 8 characters)
w Cursor
e Keyboard section
r Uppercase and lowercase switch key
t Space key
y Cursor keys
u Insert key
i Delete key
o OK key
Q0 Guide for operation buttons
Using the keyboard screen
1
Display the screen for inputting
characters
(vpage 82
“Menu map”).
2
Select a character to be changed.
q Press uio p to select or
.
w Press ENTER to place the
cursor at the character to be
changed.
Each time ENTER is pressed, the
cursor moves by one character.
3
Select a character to be input with uio p then
press ENTER.
•The types of characters that can be input are as shown below.
GUpper case characters/Numbers/SymbolsH
ABCDEFGHIJKLMNOPQRSTUVWXYZ
0123456789
! “ # $ % & ’ ( )
z
+ , ; < = >
GLower case characters/Numbers/SymbolsH
abcdefghijklmnopqrstuvwxyz
0123456789
. @ - _ / : ˜ ? [ \ ] ^ ` { | }
•When you press
SHIFT while you type in, you can change
uppercase characters to lowercase and vice versa.
4
Repeat steps 2 and 3 to change the name.
5
Use uio p to select
O K
, then press ENTER.
Basic version
Advanced version
Information
Advanced version
vSee overleaf
BD
