Denon AVR-X4000 User Manual

109
Appendix
TipsSettingsConnections
Contents
Front panel Display Rear panel IndexRemote
Playback
Playing back still pictures in sequential
order (Slideshow Interval)
You can play back still picture (JPEG) files stored on a USB memory device
or Media Server and pictures on Flickr website as a slide show. The display
time can also be set.
n Supported input sources : USB / Media Server / Flickr
1
While the list is displayed, press OPTION.
The option menu screen is displayed.
2
Use ui to select “Slideshow Interval”, then press
ENTER.
3
Use o p to set the display time.
O : The slide show is not played back.
5s – 60s : Set the time for displaying a single picture when playing
back images in the slide show.
4
Press ENTER.
The slide show is displayed on the screen.
%
•This unit plays back picture (JPEG) files in the order in which they are stored in
the folder.
Displaying your desired video during
audio playback (Video Select)
This unit can display video from a dierent source on TV during audio
playback.
You can set this for each input source.
n Supported input sources : USB / CD
z
/ HD Radio / NETWORK /
PHONO
z Available when none of HDMI, component video or video connector is
assigned.
1
Press OPTION during audio playback.
The option menu screen is displayed.
2
Use ui to select “Video Select”, then press ENTER.
3
Use o p to select the Video Select mode.
O (Default) : Disable Video Select mode.
On : Enable Video Select mode.
4
If you selected “On” in step 3, press i and select
“Source”.
5
Press o p to select the input source for video you want
to play back, and press ENTER.

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
