Denon AVR-X4000 User Manual

184
Appendix
TipsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Settings
2 Front Height
Set the presence and size of the front height speakers.
Large : Use a large speaker that can adequately play back very low
bass frequencies.
Small (Default) : Use a small speaker that has inadequate playback
capacity for very low bass frequencies. Note that this
is almost always the best choice.
None : Select when the front height speakers are not connected.
%
•When “Assign Mode” (vpage181) setting is “7.1ch (SB/FH/FW)” or
“9.1ch (SB/FH/FW)”, you can make the “Front Height” setting.
2 Front Wide
Set the presence and size of the front wide speakers.
Large : Use a large speaker that can adequately play back very low
bass frequencies.
Small (Default) : Use a small speaker that has inadequate playback
capacity for very low bass frequencies. Note that this
is almost always the best choice.
None : Select when the front height speakers are not connected.
%
•When “Assign Mode” (vpage181) setting is “7.1ch (SB/FH/FW)” or
“9.1ch (SB/FH/FW)”, you can make the “Front Wide” setting.
Distances
Set distance from listening position to speakers.
Measure beforehand the distance from the listening position to each
speaker.
2 Unit
Set the unit of distance.
Feet (Default)
Meters
2 Step
Set the minimum variable width of the distance.
1ft (Default) / 0.1ft
0.1m / 0.01m
2 Set Defaults
The “Distances” settings are returned to the default settings.
2 Set the distance
0.0ft – 60.0ft / 0.00m – 18.00m
%
•The speakers that can be selected dier depending on the “Amp Assign”
(vpage181) and “Speaker Config.” (vpage182) settings.
•Default settings :
Front L / Front R / F. Height L / F. Height R / F. Wide L / F. Wide R / Center /
Subwoofer : 12.0 ft (3.60 m)
Surround L / Surround R / Surr.Back L / Surr.Back R : 10.0 ft (3.00 m)
•Set the dierence in the distance between the speakers to less than 20.0 ft
(6.00 m).

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
