82
Appendix
TipsSettingsConnections
Contents
Front panel Display Rear panel IndexRemote
Playback
Viewing photographs shared by
particular users
1
Prepare for playback.
•Check the network environment, then turn on this unit’s power
(vpage50 “Connecting to a home network (LAN)”).
2
Press NETWORK.
3
Use uio p to select “Flickr”, then press ENTER.
Favorites Internet Radio
Media Server
Spotify
Network
4
Use ui to select “Add Flickr Contact”, then press
ENTER.
OPTION
Flickr [1/2]
Add Flickr Contact
All Content
Option
5
In “Contact”, add the screen name (user name you want
to view) you want to add.
•For character input, see page148.
6
After inputting the “Contact”, press “OK”.
The screen name is added to “Contact”, and the screen name you
entered in Step 5 is displayed on the top screen of Flickr.
•If you enter a screen name that does not exist, “The Flickr Contact
you entered could not be found” is displayed. Check and enter the
correct screen name.

Table of Contents

Other manuals for Denon AVR-X4000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X4000 and is the answer not in the manual?

Denon AVR-X4000 Specifications

General IconGeneral
Receiver type-
Frequency range10 - 100000 Hz
Output impedance16 Ω
Speaker selectorA+B
Input sensitivity200 mV
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)102 dB
Total Harmonic Distortion (THD)0.008 %
Power output per channel (1KHz@6 Ohm)165 W
Power output per channel (20-20KHz@8 Ohm)125 W
HDMI in7
AC (power) inYes
Composite video in4
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Number of HDMI outputs3
Connectivity technologyWired
Speakers connectivity typeBanana connector
Audio formats supportedAAC, FLAC, MP3, WAV, WMA
Image formats supportedJPG
Wi-FiNo
RDS featuresPTY, TP
FM band range87.5 - 108 MHz
Supported radio bandsFM
Internet radio services supportedSpotify, vTuner
Supported video modes1080i, 1080p, 480p, 576p, 720p
DisplayVFL
Color depth24 bit
Aspect ratio4:3, 16:9
Product colorSilver
Audio decodersDolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibilityNot supported
AC input voltage230 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)670 W
Weight and Dimensions IconWeight and Dimensions
Depth379 mm
Width434 mm
Height167 mm
Weight12300 g
