Denon AVR-X4000 User Manual

159
Appendix
TipsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Settings
2 Audyssey DSX
®
Provides more immersive surround sound by adding the new channels.
Wides : Turn on Audyssey DSX® processing for wide expansion.
Heights : Turn on Audyssey DSX® processing for height expansion.
Wides/Heights : Turns on Audyssey DSX® processing for wide and
height expansion.
O (Default) : Do not set Audyssey DSX®.
%
•“Audyssey DSX®” can be set when you are using front height speakers or
front wide speakers.
•“Wides/Heights” can only be set when the “Assign Mode” (vpage181)
setting is other than “9.1ch (SB/FH/FW)” and the “Main pre-amps”
(vpage182) setting is other than “Surround Back”.
•“Audyssey DSX®” is only valid when using a center speaker.
•“Audyssey DSX®” is valid when sound mode is DOLBY sound mode or DTS
sound mode other than PLgz Height and DTS NEO:X.
•“Audyssey DSX®” cannot be configured if the HD Audio source being played
includes Front height and Front wide channels. In this case, the respective
channels are played back using the input signals.
About Audyssey Dynamic Surround Expansion (A-DSX)
Audyssey DSX® is a scalable system that adds new speakers to
improve surround impression. Starting with a 5.1 system Audyssey
DSX® first adds Wide channels for the biggest impact on envelopment.
Research in human hearing has proven that information from the
Wide channels is much more critical in the presentation of a realistic
soundstage than the Back Surround channels found in traditional 7.1
systems. Audyssey DSX® then creates a pair of Height channels to
reproduce the next most important acoustical and perceptual cues.
In addition to these new Wide and Height channels, Audyssey DSX®
applies Surround Envelopment Processing to enhance the blend
between the front and surround channels.
2 Stage Width
Adjust sound stage width when using front wide speakers.
–10 – +10 (Default : 0)
2 Stage Height
Adjust sound stage height when using front height speakers.
–10 – +10 (Default : 0)

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
