Denon AVR-X4000 User Manual

141
Appendix
TipsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Settings
Setting items Description Page
Tone Adjusts the tonal quality of the sound.
154
Tone Control Set the tone control function to “On” and “O”.
154
Bass Adjust bass.
154
Treble Adjust treble.
154
Restorer Expands the low and high frequency components of compressed audio content such as MP3 files to enable richer audio
playback.
155
Audio Delay Compensates for incorrect timing between video and audio.
155
Volume Set the MAIN ZONE (room where the unit is located) volume setting.
155
Scale Set how volume is displayed.
155
Limit Make a setting for maximum volume.
156
Power On Level Define the volume setting that is active when the power is turned on.
156
Mute Level Set the amount of attenuation when muting is on.
156
Audyssey Makes Audyssey MultEQ® XT32, Audyssey Dynamic EQ®, Audyssey Dynamic Volume®, Audyssey LFC™ and Audyssey DSX®
settings.
156
MultEQ
®
XT32 MultEQ® XT32 compensates for both time and frequency characteristics of the listening area based on Audyssey® Setup
measurement results.
156
Dynamic EQ Solves the problem of deteriorating sound quality as volume is decreased by taking into account human perception and room
acoustics. Works with MultEQ® XT32.
157
Reference Level Oset Audyssey Dynamic EQ® is referenced to the standard film mix level.
157
Dynamic Volume Solves the problem of large variations in volume level between TV, movies and other content (between quiet passages and
loud passages, etc.) by automatically adjusting to the user’s preferred volume setting.
158
Audyssey LFC™ Adjusts the low frequency band to prevent bass and vibration from being conveyed to neighboring rooms.
158
Containment Amount Adjusts the amount of low frequency containment. Use higher settings if you have close neighbors.
158
Audyssey DSX
®
Provides more immersive surround sound by adding the new channels.
159
Stage Width Adjust sound stage width when using front wide speakers.
159
Stage Height Adjust sound stage height when using front height speakers.
159

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
