12
2. CX870 MODULE
(1) Remove the screws.
(2) Disconnect the CX870 module.
BOTTOM COVER
→
MAIN PWB
CX870 MODULE
→
Proceeding :
Shooting direction: C
Shooting direction: D
CX870 module
