7. AMPLIFIER PWB UNIT
(1) Remove the screws.
SPEAKER GRILL NET
FRONT CABINET
REMOVE DUCT
Proceeding :
WOOFER
DOCK & OLED ASSY
AMP PWB UNIT
Shooting direction: C
Wire for TW
Wire for Woofer
Wire to MAIN PWB
Wire from POWER PWB
