15
4. SPEAKER DRIVER (TWEETER)
(1) Remove the screws of Duct.
(2) Remove the screws of Tweeter.
SPEAKER GRILL NET
→
FRONT CABINET
→
Proceeding : REMOVE DUCT
TWEETER
→
Shooting direction: B
Shooting direction: B
