Denon HEOS - Bottom

o
Bottom
.
e
qq
wr
w
A
Keyhole (for wall mount)
B
Threaded mounting hole (for wall mount)
Used to mount this unit on a wall or ceiling.
C
Status LED (for wall mount)
Please refer to the “Status LED table” for LED color and state meaning. (v
p. 68)
D
Status LED (for tabletop)
Please refer to the “Status LED table” for LED color and state meaning. (v
p. 68)
