8514-296-001 REV K page 47
2.8 PLUMBING
Water supply hoses are provided with each machine. The threaded
connections on the hoses are ¾-11 ½ NHT for 60 Hz models and ¾-14
BSP for 50 Hz models.
Separate hot and cold water lines must be supplied to the machine,
maintaining 30 psi to 120 psi (207 kPa to 827 kPa) water flow pressure. A
140°F (60°C) hot water supply is recommended for best washing results.
Do not exceed 180°F (82°C) water temperature.
2.9 DRAIN
The drain outlet tube size:
For T-300 and 350 is 2 ¼ inches (57 mm) in diameter,
and for all other models is 3 inches (76 mm) in diameter.
Any drain hose used must be lower than the drain valve to assure proper
draining.
2.10 PROTECTIVE FILM
The machine may have protective adhesive film on the front control panel
label area and on the front, top, and side stainless steel panels. The film
may be peeled off before putting the machine into service.
2.11 ELECTRICAL
The Dexter washing machines are intended to be permanently installed
appliances. No power cord is provided. The machine should be
connected to an individual branch circuit not shared by lighting or other
equipment. A means for disconnection with a contact separation of at
least 1/8” (3 mm) must be provided. The connection should be sheathed
in liquid-tight or approved flexible conduit, or equivalent, with conductors
of the proper size and insulation (50 Hz: The sheath of the supply cord
must be at least equivalent to that of a cord complying with IEC 227 or
IEC 245). A qualified technician should make such connections in
accordance with the wiring diagram. See specification sheet for minimum
recommended wire size.
Individual circuit breakers for each unit are required. Do not use ground-
fault (earth-fault) circuit breakers or ground-fault (earth-fault) circuit
interrupter outlets.
