Dexter Laundry T-950 User Manual

8514-296-001 REV K page 6
1.2 Express Washers
Capacity Dry Weight Capacity - lb (kg) 20 (9.1) 30 (13.6) 40 (18.1) 50 (22.7) 60 (27.2) 90 (40.8)
Cylinder Volume - cu ft (L) 2.7 (76.5) 3.8 (107.6) 6 (170) 6.5 (184.1) 9 (254.9) 13.7 (388)
Speed High Extract Speed - g (RPM) 200 (819) 200 (750) 200 (750) 200 (685) 200 (685) 200 (617)
Intermediate Extract Speed - g (RPM) 60 (449) 60 (411) 60 (411) 60 (375) 60 (375) 60 (338)
Washing Speed - g (RPM) 0.9 (55) 0.9 (50) 0.9 (50) 0.9 (43) 0.9 (43) 0.9 (39)
Motor Size - hp (kW) 1 (0.75) 2 (1.5) 2 (1.5) 3 (2.2) 3 (2.2) 6.7 (5)
Dimensions Cabinet Height - in (cm) 43 7/8 (111.4) 48 3/16 (122.4) 53 (134.6) 55 3/8 (140.7) 55 3/8 (140.7) 62 3/8 (158.4)
Cabinet Width - in (cm) 26 (66) 29 7/8 (75.9) 29 7/8 (75.9) 34 3/8 (87.3) 34 3/8 (87.3) 41 1/2 (105.4)
Cabinet Depth - in (cm) 28 (71.1) 28 1/4 (71.8) 38 1/8 (96.8) 32 7/8 (83.5) 38 7/8 (98.7) 42 1/4 (107.3)
Door Opening - in (cm) 12 1/4 (31.1) 15 1/4 (38.7) 15 1/4 (38.7) 19 1/4 (48.9) 19 1/4 (48.9) 19 1/4 (48.9)
Floor to Door Bottom - in (cm) 14 7/8 (37.8) 16 1/4 (41.3) 16 1/4 (41.3) 16 (40.6) 16 (40.6) 19 5/16 (49.1)
Cylinder Diameter - in (cm) 21 (53.3) 25 (63.5) 25 (63.5) 30 (76.2) 30 (76.2) 37 (94)
Cylinder Depth - in (cm) 13 1/2 (34.3) 13 3/8 (34) 21 1/8 (53.7) 16 (40.6) 22 (55.9) 22 (55.9)
Weight Net Weight - lb (kg) 383 (173.7) 526 (238.6) 744 (337.5) 925 (419.6) 1000 (453.6) 1322 (599.6)
Shipping Shipping Weight - lb (kg) 407 (184.6) 544 (246.8) 766 (347.5) 952 (431.8) 1016 (460.8) 1364 (618.7)
Shipping Height - in (cm) 49 1/4 (125.1) 53 1/4 (135.3) 58 3/4 (149.2) 61 1/2 (156.2) 61 1/2 (156.2) 69 1/4 (175.9)
Shipping Width - in (cm) 28 1/4 (71.8) 31 1/2 (80) 31 1/2 (80) 36 (91.4) 36 (91.4) 43 1/8 (109.5)
Shipping Depth - in (cm) 33 1/2 (85.1) 33 1/2 (85.1) 43 3/4 (111.1) 38 (96.5) 45 1/4 (114.9) 48 (121.9)
Water Water Inlet Size - in (mm) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19)
Pressure (min-max) - psi (kPa) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827)
Flow Rate - gal/min (L/min) 9 (34) 9 (34) 9 (34) 9 (34) 9 & 12 (34 & 45) 9 & 12 (34 & 45)
Approx. Water Usage Per - gal (L) 15.8 (59.8) 22.2 (84) 35.1 (132.9) 38.4 (145.4) 52.6 (199.1) 80.1 (303.2)
Drain Diameter (O.D.) - in (cm) 2 1/4 (5.7) 3 (7.6) 3 (7.6) 3 (7.6) 3 (7.6) 3 (7.6)
Floor to Center of Drain - in (cm) 6 (15.2) 5 (12.7) 6 7/8 (17.5) 6 5/8 (16.8) 6 5/8 (16.8) 8 5/16 (21.1)
Electrical Model Volts / Hz / Phase / Wiring
208-240 / 60 / 1 / 2 wire + ground
208-240 / 60 / 3 / 3 wire + ground
-39 230 / 50 / 1 / 2 wire + ground
-59 230 / 50 / 1 / 2 wire + ground
Installation Min. Clearance Between Machines - in (cm) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3)
Min. Clearance Behind Machines - in (cm 24 (61) 24 (61) 24 (61) 24 (61) 24 (61) 24 (61)
Min. Concrete Thickness - in (cm) 6 (15.2) 6 (15.2) 8 (20.3) 8 (20.3) 8 (20.3) 12 (30.5)
-12 30 / 15 / #10
20 / 8.4 / 3.5 mm²
20 / 8.4 / 3.5 mm²
30 / 15 / 5.3 mm²
---
20/ 8.4 / #12 20/ 12 / #12
15 / 6.2 / 3.5 mm²
15 / 6.2 / 3.5 mm²
20 / 12 / 3.5 mm²
---
15 / 6.2 / #12
15 / 6.2 / 3.5 mm
²
15 / 6.2 / 3.5 mm²
15 / 6.2 / 3.5 mm²
15 / 6.2 / 3.5 mm²
15 / 6.2 / #12 15 / 6.2 / #12
Circuit Breaker Amps / Running Amps / Wire Size
T-750
T-350
T-450
T-650
T-950
T-1450
NOTE:
For some models, Final Extract Speed is dependent on load and incoming voltage. Refer to the Electrical Installation section for more details.

Dexter Laundry T-950 Specifications

General

Brand	Dexter Laundry
Model	T-950
Category	Washer
Language	English
