Dexter Laundry T-950 User Manual

8514-296-001 REV K page 5
1 WASHER SPECIFICATION SHEET
1.1 Standard Washers
Capacity Dry Weight Capacity - lb (kg) 20 (9.1) 30 (13.6) 40 (18.1) 60 (27.2) 80 (36.3) 120 (54.4)
Cylinder Volume - cu ft (L) 2.7 (76.5) 4 (113.3) 6 (170) 9 (254.9) 11.5 (325.6) 17.4 (492.7)
Speed High Extract Speed - g (RPM) 100 (579) 100 (532) 100 (532) 100 (485) 100 (485) 100 (436)
Intermediate Extract Speed - g (RPM) 60 (449) 60 (412) 60 (412) 60 (375) 60 (375) 60 (338)
Washing Speed - g (RPM) 0.9 (55) 0.9 (50) 0.9 (50) 0.9 (43) 0.9 (43) 0.9 (39)
Motor Size - hp (kW) 1 (0.75) 2 (1.5) 2 (1.5) 3 (2.2) 3 (2.2) 7.8 (5.8)
Dimensions Cabinet Height - in (cm) 43 7/8 (111.4) 48 3/16 (122.4) 49 11/16 (126.2) 55 3/8 (140.7) 57 7/8 (147) 62 3/8 (158.4)
Cabinet Width - in (cm) 26 (66) 29 7/8 (75.9) 29 7/8 (75.9) 34 3/8 (87.3) 34 3/8 (87.3) 41 1/2 (105.4)
Cabinet Depth - in (cm) 25 (63.5) 27 3/8 (69.5) 36 (91.4) 38 7/8 (98.8) 45 3/8 (115.3) 48 1/4 (122.6)
Door Opening - in (cm) 12 1/4 (31.1) 15 1/4 (38.7) 15 1/4 (38.7) 19 1/4 (48.9) 19 1/4 (48.9) 19 1/4 (48.9)
Floor to Door Bottom - in (cm) 14 7/8 (37.8) 16 1/4 (41.3) 16 1/4 (41.3) 16 (40.6) 18 1/2 (47) 19 5/16 (49.1)
Cylinder Diameter - in (cm) 21 (53.3) 25 (63.5) 25 (63.5) 30 (76.2) 30 (76.2) 37 (94)
Cylinder Depth - in (cm) 13 1/2 (34.3) 14 1/8 (35.9) 21 1/8 (53.7) 22 (55.9) 28 (71.1) 28 (71.1)
Weight Net Weight - lb (kg) 317 (143.8) 432 (196) 558 (253.1) 964 (437.3) 1022 (463.6) 1415 (641.8)
Shipping Shipping Weight - lb (kg) 340 (154.2) 450 (204.1) 580 (263.1) 980 (444.5) 1063 (482.2) 1460 (662.2)
Shipping Height - in (cm) 50 (127) 53 1/4 (135.3) 54 3/4 (139.1) 61 1/2 (156.2) 63 3/4 (161.9) 69 1/4 (175.9)
Shipping Width - in (cm) 27 1/4 (69.2) 31 1/2 (80) 31 1/2 (80) 36 (91.4) 36 (91.4) 43 1/8 (109.5)
Shipping Depth - in (cm) 30 1/2 (77.5) 33 1/2 (85.1) 41 (104.1) 44 1/4 (112.4) 52 3/16 (132.6) 54 (137.2)
Water Water Inlet Size - in (mm) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19)
Pressure (min-max) - psi (kPa) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827) 30-120 (207-827)
Flow Rate - gal/min (L/min) 9 (34) 9 (34) 9 (34) 9 (34) 9 & 12 (34 & 45) 9 & 12 (34 & 45)
Approx. Water Usage Per Cycle - gal (L) 15.8 (59.8) 23.5 (89) 35.1 (132.9) 52.6 (199.1) 67 (253.6) 95.6 (361.9)
Drain Diameter (O.D.) - in (cm) 2 1/4 (5.7) 3 (7.6) 3 (7.6) 3 (7.6) 3 (7.6) 3 (7.6)
Floor to Center of Drain - in (cm) 6 (15.2) 4 11/16 (11.9) 5 (12.7) 6 5/8 (16.8) 8 5/8 (21.8) 8 5/16 (21.1)
Electrical Model Volts / Hz / Phase / Wiring
-10 120 / 60 / 1 / 2 wire + ground
208-240 / 60 / 1 / 2 wire + ground
208-240 / 60 / 3 / 3 wire + ground
-39 230 / 50 / 1 / 2 wire + ground
-59 230 / 50 / 1 / 2 wire + ground
Installation Min. Clearance Between Machines - in (cm) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3)
Min. Clearance Behind Machines - in (cm 24 (61) 24 (61) 24 (61) 24 (61) 24 (61) 24 (61)
Min. Concrete Thickness - in (cm) 6 (15.2) 6 (15.2) 6 (15.2) 8 (20.3) 8 (20.3) 12 (30.5)
T-1200
20 / 13 / #12
---
-12
T-300
T-400
T-600
T-900
20 / 8.4 / 3.5 mm²
15 / 4 / 3.5 mm²
15 / 4 / 3.5 mm²
---
15 / 6.2 / 3.5 mm²
15 / 4 / #12 15 / 6.2 / #12
15 / 6.2 / 3.5 mm²
T-1800
---
30 / 16.6 / #10
30 / 16.6 / 5.3 mm²
---
Circuit Breaker Amps / Running Amps / Wire Size
15 / 6.2 / 3.5 mm²
15 / 6.2 / 3.5 mm²
---
20 / 8.4 / 3.5 mm²
---
---
20 / 8.4 / 3.5 mm²
15 / 6.2 amp / #12 20 / 8.4 / #12 20 / 8.4 / #12
