UART 1 Status LEDs
UART 2 Status LEDs
XBee Assoc., LE50
This LED is connected to the Associate output of the Digi XBee module. This LED provides
information of the device's network status and diagnostics information. For a more in-depth
description of this LED please refer to the Digi XBee modules documentation available at
www.digi.com.
LED Reference Function
RED GREEN
LE60 LE45 TXD
LE61 LE46 RXD#
LE62 LE47 RTS#
LE63 LE48 CTS#
LED Reference Function
RED GREEN
LE41 LE40 TXD
LE57 LE42 RXD
LE58 LE43 RTS#
LE59 LE44 CTS#
