Instructions for use BiliLux 27
Operating concept
5 Operating concept
5.1 Control panel
010
Keys (fixed function)
A Key to start, pause, and resume therapy.
B Key to decrease irradiance of phototherapy light in 5 decrements of 20%. The
LED indicators above the key turn off in succession each time the key is
pressed. The available settings are 20%, 40%, 60%, 80%, and 100%.
C Key to increase irradiance of phototherapy light in 5 increments of 20%. The
LED indicators above the key illuminate in succession each time the key is
pressed. The available settings are 20%, 40%, 60%, 80%, and 100%.
D On/off key for observation light. The observation light operates independently
of the phototherapy light.
E Menu key used to select among various operational and service screens.
Buttons (variable function)
F Buttons whose functions are defined on the currently selected screen.
LED indicators
G LED indicators for irradiance of phototherapy light. Each bar represents an
increment of 20%. One bar indicates 20% irradiance and five bars indicates
100% irradiance.
H On/Off LED indicator for observation light.
