50 Instructions for use BiliLux
Operation
8.5 Exporting a phototherapy report
The phototherapy report screen allows the user to export the report for a completed
phototherapy session to a USB flash drive. A report can be exported only after
phototherapy is ended.
Use only approved USB flash drives that are included in the "List of accessories"
on page 83.
1 Ensure that therapy is ended (see Ending phototherapy on page 52).
2 Ensure that the USB flash drive is connected to the USB port on the rear of the
phototherapy light.
3 Press the key repeatedly until the Phototherapy report screen is
displayed.
4 Press the Export button (A).
5 The message Delete all stored values after export? is displayed on the
screen.
Press the Confirm button to delete all stored values after successful export
of the phototherapy report.
Press the Cancel button to retain stored values after successful export of the
phototherapy report.
6 When the export process is complete, the message Successful is displayed on
the screen.
If export is attempted when a USB flash drive is not connected or if export to the
USB flash drive was not successful, the message USB error is displayed on the
screen and the export does not complete.
If export is attempted during active phototherapy, the message No export
during running therapy. is displayed on the screen and the export does not
complete.
The phototherapy report contains entries for the following events:
Phototherapy start/end/pause/resume events with their times and dates
Irradiance measurements made with the optional radiometer during therapy with
their times and dates
Therapy duration after phototherapy is ended
Changes to the irradiance setting in % (entered in report after the new setting
remains unchanged for more than 1 minute)
Time/date changes
