Abbreviations and symbols
Air Mix Mixture of O2 and ambient air
(= approx. 60 vol.% O2)
CPAP Continuous Positive Airway Pressure
– Breathing with positive airway pressure
CPR Cardio-pulmonary resuscitation
IPPV Intermittent Positive Pressure Ventilation
KG Body weight in kg
MV Minute volume, L/min
No Air Mix O2 is not mixed with ambient air (= 100 vol.% O2)
Paw Airway pressure
Paw high Upper alarm limit for airway pressure
Paw low Lower alarm limit for airway pressure
PEEP Positive End Exspiratory Pressure
Pmax Setting for upper alarm limit for airway pressure »Paw high«
Reset Reset = clear
SIMV Synchronized Intermittent Mandatory Ventilation
SIPPV Synchronized Intermittent Positive Pressure Ventilation
TI : TE Ratio of inspiration time to expiration time
*
Synchronized ventilation stroke for SIPPV and SIMV
ª
Setting symbol for ventilation frequency 12 1/min and Pmax 80 mbar for
cardio-pulmonary resuscitation
g
Key to suppress alarm tone for approx. 2 minutes
and to reset the alarm message when the fault has been rectified = clear
Alarm indicator, lights up red in the event of an alarm
LED for »external DC power available«, lights up green
[
Observe Instructions for Use
m
Protection class BF (body floating)
Safety transformer, short-circuit proof
For indoor use only
Thermal fuse
Protective insulation (protection class II)
